Full Description

Features

• 18" active subwoofer with 1000 watts of continuous power
• Class D amplifier drives the LF tranducer
• No fans needed thanks to convection cooling
• Maximum efficiency and high SPL using perfect combinationg of the amplifier and the custom LF driver
• Both XLR and jack balanced inputs to choose from
• Adjustable low pass filter to get the system sounding its best
• Balanced thru output and HPF output for active full-range models
• Attach full-range models with top 35mm pole socket
• Sturdy plywood case painted with durable Rhino Rock paint
• Carry easily using the rubberised handles
• Optional rubber feet for secure positioning

Specifications

• System Type: active 18" subwoofer
• Frequency Response (±3dB): 38Hz - 200Hz
• Calculated Maximum SPL @ 1m: 132dB
• Low Frequency Transducer:
  • Size: 18"
  • Voice Coil Size: 4"
  • Impedance: 8Ω
• Low-Frequency Power Amplifier RMS: 1000W (Class D)
• Protection: amplifier, power on, thermal, driver, low line voltage shut down, DC and short, clip limiter
• Connectors:
  • Input A - Type: balanced
  • Input Sensitivity: line - 0dBu
  • Maximum Input Level: 22dBu
  • Input: TRS jack and female XLR
  • Input Impedance: balanced - 20KΩ, unbalanced 10KΩ
  • Live Output Connector: male XLR connector
• Impedance Balanced: balanced 200Ω, unbalanced 100Ω
• Loop Gain: 0dB
• Power:
  • Power Supply: high efficiency SMPS
  • AC Power Options: 100-120V/220-240V, 50/60Hz
• Enclosure:
  • Material: 15mm plywood
  • Colour: black
• Dimensions:
  • Height: 531mm
  • Width (Front): 531mm
  • Width (Back): 531mm
  • Depth: 650mm
• Weight: 38.4
