The PM-322P features eight line and two phono inputs, accessible via the back of the mixer. This provides enough room to input various sources simultaneously. Having four channels is also ideal for quick switching when working with multiple DJ's. A microphone input is included for announcements, with independent volume control and 2-band EQ.
Versatile output options
The master output can be accessed via balanced RCA and XLR outputs. An independent master rec-out also allows recordings to be made without interfering with the mastering output. A booth output is also accessible for independent monitoring from the master outputs. This is separate to the headphone output.
Wireless transmission channel with Bluetooth connectivity
In addition to the four channels, a separate channel is available for external audio devices. A USB input can be used to attach an MP3, ideal for playing music between DJ sets. Alternatively, devices with Bluetooth can be connected to the mixer via this channel. This allows for wireless music transmission from mobile phones, tablets or laptops.
Features
4 input channels with gain control, LED level meter, 3-band equalizer, cue button and channel fader
DJ microphone channel with level control, 2-band equalizer, on/off and talkover switch
Integrated Bluetooth audio streaming for your smartphones and tablets
MP3 player with USB port and blue LCD screen
Pre-fader listening to all input channels and the master output via adjustable stereo headphones output
Crossfader with assignment switches and adjustable curve
Master channel with level and balance control
10-digit stereo LED level meter
Adjustable monitor output (DJ booth)
10 line and 2 phono inputs via RCA jacks
Balanced XLR and RCA outputs
Record output, independent of the master
Specifications
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 25 W
Audio player: USB + Bluetooth
Format: MP3
Range: 10 m
Carrier frequency: 2,4 GHz
Length: 35 cm
Width: 26,6 cm
Height: 10,5 cm
Weight: 3,46 kg
Inputs:
Line/phono: stereo RCA, switchable
Line: stereo RCA
DJ microphone: XLR, bal. and 6.3 mm jack, unbal.
Outputs:
Master: stereo XLR and RCA
Booth: stereo RCA
Record: stereo RCA
Headphones output: 3.5 mm and 6.3 mm stereo jack
Bluetooth: version 4.2+ EDR
Profiles: A2DP, AVRCP
Audio player:
Playback format: MP3, WMA, WAV
Available storage media: USB devices up to 32 GB (FAT32)
